Tlhaloso: STM8L101F3U6ATR IC MCU 8BIT 8KB FLASH 20UFQFPN

Tlhaloso e Khutšoanyane:

Setšoantšo sa STM8L101F3U6ATR

Moetsi: STMicroelectronics
Sephutheloana: 20-UFQFN
Tlhaloso: STM8 series Microcontroller IC 8-Bit 16MHz 8KB (8K x 8) FLASH 20-UFQFPN (3×3)

Datasheet: Ka kopo ikopanye le rona.


Lintlha tsa Sehlahisoa

Li-tag tsa Sehlahisoa

Parameter ea sehlahisoa

Tlhaloso

Lelapa la STM8L101x1 STM8L101x2 STM8L101x3 le nang le matla a tlase le na le setsi se ntlafalitsoeng sa STM8 CPU se fanang ka matla a eketsehileng a ho sebetsa (ho fihla ho 16 MIPS ho 16 MHz) ha se ntse se boloka melemo ea meralo ea CISC e nang le khoutu e ntlafetseng, sebaka sa 24-bit le sebaka sa ho sebetsana le maemo. meaho bakeng sa ts'ebetso ea matla a tlase.Lelapa le kenyelletsa mojule oa ho lokisa o kopantsoeng o nang le sebopeho sa Hardware (SWIM) se lumellang hore ho se ke ha e-ba le ts'ebetso ea ts'ebetso ea ts'ebetso ea ts'ebetso e sa keneleng le ho etsa mananeo a Flash a potlakileng.Li-microcontrollers tsohle tsa STM8L101xx li na le matla a tlase a motlakase a le mong oa sesebelisoa sa Flash memory.Lisebelisoa tsa 8-Kbyte li kenya data EEPROM.Lelapa la matla a tlase la STM8L101xx le thehiloe ho sete e akaretsang ea li-peripherals tsa boemo bo holimo.Sebopeho sa modular sa sete sa peripheral se lumella hore li-peripherals tse tšoanang li fumanoe malapeng a fapaneng a ST microcontroller ho kenyeletsa le malapa a 32-bit.Sena se etsa hore phetoho leha e le efe ea ho ea lelapeng le fapaneng e be bonolo haholo, 'me e nolofatsoe le ho feta ka tšebeliso ea lisebelisoa tse tloaelehileng tsa ntlafatso.Lihlahisoa tsohle tse tlase tsa STM8L li thehiloe moahong o tšoanang o nang le 'mapa o tšoanang oa memori le pinout e lumellanang.



Litlhaloso:
Tšobotsi Boleng
Sehlopha Lipotoloho tse Kopantsoeng (ICs)
E kenyelelitsoe - Li-microcontroller
Mfr STMicroelectronics
Letoto Tlhaloso: STM8L EnergyLite
Sephutheloana Theipi le Reel (TR)
Seha Tape (CT)
Digi-Reel®
Boemo ba Karolo E sebetsa
Core processor STM8
Boholo ba Core 8-Bit
Lebelo 16MHz
Khokahano I²C, SPI, UART/USART
Pheripherals Infrared, POR, PWM, WDT
Nomoro ea I/O 18
Boholo ba Memori ea Lenaneo 8KB (8K x 8)
Mofuta oa Memori ea Lenaneo LEHLANYA
EEPROM Boholo 2K x 8
Boholo ba RAM 1.5K x 8
Voltage - Phepelo (Vcc/Vdd) 1.65V ~ 3,6V
Bafetoleli ba Lintlha -
Mofuta oa Oscillator Ka hare
Mocheso oa ho sebetsa -40°C ~ 85°C (TA)
Mofuta oa ho Beha Thaba e kaholimo
Sephutheloana / Taba 20-UFQFN
Sephutheloana sa Sesebelisoa sa Bafani 20-UFQFPN (3x3)
Nomoro ea Sehlahisoa sa Motheo STM8



Setšoantšo sa STM8L101 1



STM8L101 2
